ICC/IF analysis of HEK293 cells using GTX23533 PC2 antibody. Cells were probed without (left) or with(right) an antibody.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : Formalin
Permeabilization : 0.1% Triton X-100 in TBS for 5-10 minute
Dilution : 1:100 incubated overnight at 4 ºC

WB analysis of 25 ug of mouse cerebellum cell lysates using GTX23533 PC2 antibody.
Dilution : 1:500

ICC/IF analysis of C2C12 cells using GTX23533 PC2 antibody. Cells were probed without (left) or with(right) an antibody.
Green : Primary antibody
Blue : Nuclei
Red : Actin
Fixation : Formalin
Permeabilization : 0.1% Triton X-100 in TBS for 5-10 minute
Dilution : 1:100 incubated overnight at 4 ºC
