ATM antibody [5C2]

Orthogonal

Cat No. GTX70107

Host Mouse
Clonality Monoclonal
Clone Name 5C2
Isotype IgG1
Application WB, ICC/IF, IP, IHC
Reactivity Human, Mouse, Rat, Monkey
APPLICATION

Application Note

For ICC/IF: 1:100-1:1000. For WB: 1:500-1:3000. Predicated molecular weight: 350 kDa. Optimal dilutions/concentrations should be determined by the researcher.

Calculated MW

370 kDa. ( Note )

Positive Control

Raji , HeLa nuclear extract
PROPERTIES

Form

Liquid

Buffer

PBS

Storage

Store as concentrated solution. Centrifuge briefly prior to opening vial. For short-term storage (1-2 weeks), store at 4ºC. For long-term storage, aliquot and store at -20ºC or below. Avoid multiple freeze-thaw cycles.

Concentration

0.96mg/ml(Please refer to the vial label for the specific concentration.)

Antigen Species

Human

Immunogen

Recombinant protein expressed in E. coli corresponding to amino acids 980-1512.

Purification

Protein G purified

Conjugation

Unconjugated

Note

For laboratory use only. Not for any clinical, therapeutic, or diagnostic use in humans or animals. Not for animal or human consumption.
TARGET

Synonyms

ATD, 114480, ATA, AT1, ATC, ATE, DKFZp781A0353, 472, ATM, TEL1, ATDC, Q13315, MGC74674

Cellular Localization

Nuclear

Background

ATM-5C2 recognizes full-length ATM, a 370kDa nuclear phosphoprotein, which is involved in the autosomal recessive disease ataxia telangiectasia (AT). ATM belongs to a novel family of proteins associated with cell cycle regulation and response to DNA repair. The C-terminal region has extensive homology to the catalytic domains of phosphatidylinositol 3-kinases (PI3 kinases). Its usefulness to monitor altered ATM expression in cancer is under active investigation.

Database

Research Area

DATA IMAGES

GTX70107 WB Image

Orthogonal

ATM antibody detects ATM protein by Western blot analysis. HeLa whole cell extracts and nuclear extracts (30 μg) were separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody (GTX70107) diluted at 1:500. The signal was developed with Trident femto Western HRP Substrate (GTX14698).


GTX70107 WB Image

Orthogonal

HeLa whole cell and nuclear extracts (30 µg) were separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody [5C2] (GTX70107) diluted at 1:1000. The HRP-conjugated anti-mouse IgG antibody (GTX213111-01) was used to detect the primary antibody, and the signal was developed with Trident ECL plus-Enhanced.


GTX70107 ICC/IF Image

ATM antibody [5C2] detects ATM protein at nucleus by immunofluorescent analysis.
Sample: HeLa cells were fixed in 4% paraformaldehyde at RT for 15 min.
Green: ATM protein stained by ATM antibody [5C2] (GTX70107) diluted at 1:200.
Blue: Hoechst 33342 staining.
Scale bar = 10 μm.


GTX70107 WB Image

Detection of human ATM protein using GeneTex ATM 5C2 monoclonal antibody (GTX70107) in Raji whole cell extract (lane 1) and T24 syncronized cell lysate (lane 2). Also available 200ug size GTX70108.

The HRP-conjugated anti-mouse IgG antibody (GTX213111-01) was used to detect the primary antibody.


GTX70107 WB Image

Orthogonal

ATM antibody detects ATM protein by western blot analysis. HeLa whole cell extracts and nuclear extracts (30 µg) were separated by 5% SDS-PAGE, and the membrane was blotted with ATM antibody (GTX70107) diluted at 1:1000. The HRP-conjugated anti-mouse IgG antibody (GTX213111-01) was used to detect the primary antibody, and the signal was developed with Trident femto Western HRP Substrate (GTX14698).
