MAP2 antibody

Name: MAP2 antibody
Brand: GeneTex
SKU: GTX133109
Price: 329.00 USD

Anti-MAP2 antibody used in Immunocytochemistry/ Immunofluorescence (ICC/IF). GTX133109

Anti-MAP2 antibody used in Western Blot (WB). GTX133109

Anti-MAP2 antibody used in IHC (Paraffin sections) (IHC-P). GTX133109

Anti-MAP2 antibody used in IHC (Frozen sections) (IHC-Fr). GTX133109

Cat No. GTX133109

Reference 2

Host	Rabbit
Clonality	Polyclonal
Isotype	IgG
Application	WB, ICC/IF, IHC-P, IHC-Fr
Reactivity	Mouse, Rat
Package	100 μl ($329), 25 μl ($169)

See all MAP2 products

APPLICATION

Application Note

*Optimal dilutions/concentrations should be determined by the researcher.

Application	Dilution
WB	1:500-1:3000
ICC/IF	1:100-1:1000
IHC-P	1:100-1:1000
IHC-Fr	1:100-1:1000

Not tested in other applications.

Calculated MW

199 kDa. ( Note )

Positive Control

mouse brain , DIV9 rat E18 primary cortical neurons

PROPERTIES

Form

Liquid

Buffer

1XPBS, 1% BSA, 20% Glycerol (pH7). 0.025% ProClin 300 was added as a preservative.

Storage

Store as concentrated solution. Centrifuge briefly prior to opening vial. For short-term storage (1-2 weeks), store at 4ºC. For long-term storage, aliquot and store at -20ºC or below. Avoid multiple freeze-thaw cycles.

Concentration

0.15 mg/ml (Please refer to the vial label for the specific concentration.)

Antigen Species

Mouse

Immunogen

Carrier-protein conjugated synthetic peptide encompassing a sequence within the N-terminus region of Mouse MAP2. The exact sequence is proprietary.

Purification

Purified by antigen-affinity chromatography.

Conjugation

Unconjugated

Note

For laboratory use only. Not for any clinical, therapeutic, or diagnostic use in humans or animals. Not for animal or human consumption.

TARGET

Synonyms

microtubule-associated protein 2 , G1-397-34 , MAP-2 , Mtap-2 , Mtap2 , repro4

Cellular Localization

Cytoplasm, cytoskeleton,Cell projection, dendrite

Database

Gene ID: 17756 Map2
UniProt: P20357 Map2

Research Area

DATA IMAGES

GTX133109 ICC/IF Image

MAP2 antibody detects MAP2 protein at cytoplasm by immunofluorescent analysis.
Sample: DIV9 rat E18 primary cortical neurons were fixed in 4% paraformaldehyde at RT for 15 min.
Green: MAP2 protein stained by MAP2 antibody (GTX133109) diluted at 1:500.
Red: Tau, stained by Tau antibody (GTX49353 ) diluted at 1:500.
Blue:Fluoroshield with DAPI (GTX30920).

GTX133109 WB Image

Mouse tissue extract (10 μg) was separated by 5% SDS-PAGE, and the membrane was blotted with MAP2 antibody (GTX133109) diluted at 1:1000. The HRP-conjugated anti-rabbit IgG antibody (GTX213110-01) was used to detect the primary antibody.

GTX133109 ICC/IF Image

MAP2 antibody detects MAP2 protein in dendrites, but not in axons, by immunofluorescent analysis .
Sample: DIV9 rat E18 primary cortical neurons were fixed in 4% paraformaldehyde at RT for 15 min.
Grenn: MAP2 protein stained by MAP2 antibody (GTX133109) diluted at 1:500.
Red (Top right): Dendrites, stained by MAP2 antibody [HM-2] (GTX11267) diluted at 1:1000.
Red (Bottom right): Axons, stained by Tau antibody (GTX49353 ) diluted at 1:500.
Blue: Fluoroshield with DAPI (GTX30920).

GTX133109 IHC-P Image

MAP2 antibody detects MAP2 protein at cytoplasm in mouse brain by immunohistochemical analysis.
Sample: Paraffin-embedded mouse brain.
MAP2 antibody (GTX133109) diluted at 1:500.

Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

GTX133109 IHC-P Image

MAP2 antibody detects MAP2 protein at cytoplasm in rat brain by immunohistochemical analysis.
Sample: Paraffin-embedded rat brain.
MAP2 antibody (GTX133109) diluted at 1:500.

Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

GTX133109 ICC/IF Image

MAP2 antibody detects MAP2 protein at cytoplasm by immunofluorescent analysis.
Sample: DIV9 rat E18 primary cortical neurons were fixed in 4% paraformaldehyde at RT for 15 min.
Green: MAP2 protein stained by MAP2 antibody (GTX133109) diluted at 1:500.
Red: MAP2, stained by MAP2 antibody [HM-2] (GTX11267) diluted at 1:1000.
Blue: Fluoroshield with DAPI (GTX30920).

GTX133109 IHC-Fr Image

MAP2 antibody detects MAP2 protein expression by immunohistochemical analysis.
Sample: Frozen-sectioned adult mouse cerebellum.
Green: MAP2 protein stained by MAP2 antibody (GTX133109) diluted at 1:250.
Red: Tau, stained by Tau antibody (GTX49353) diluted at 1:500.
Blue: Fluoroshield with DAPI (GTX30920).

GTX133109 IHC-P Image

MAP2 antibody detects MAP2 protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded rat cerebellum.
Green: MAP2 stained by MAP2 antibody (GTX133109) diluted at 1:250.
Blue: Fluoroshield with DAPI (GTX30920).
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

GTX133109 IHC-P Image

MAP2 antibody detects MAP2 protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded mouse cerebellum.
Green: MAP2 stained by MAP2 antibody (GTX133109) diluted at 1:250.
Blue: Fluoroshield with DAPI (GTX30920).
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

GTX133109 ICC/IF Image

MAP2 antibody detects MAP2 protein in dendrites, but not in axons, by immunofluorescent analysis.
Sample: DIV10 rat E18 primary cortical neuron cells were fixed in 4% paraformaldehyde at RT for 15 min.
Green: MAP2 stained by MAP2 antibody (GTX133109) diluted at 1:500 and 1:5000.
Red: Axon marker Tau, stained by Tau antibody [GT287] (GTX634809) diluted at 1:500.
Blue: Fluoroshield with DAPI (GTX30920).

GTX133109 IHC-P Image

MAP2 antibody detects MAP2 protein at cytoplasm by immunohistochemical analysis.
Sample: Paraffin-embedded mouse brain.
MAP2 stained by MAP2 antibody (GTX133109) diluted at 1:2000.
Antigen Retrieval: Citrate buffer, pH 6.0, 15 min

GTX133109 IHC-P Image

REFERENCE

Application Reference

Ruiz-Palacios M et al. Sci Total Environ 2020; 708 : 134821 Establishment of a brain cell line (FuB-1) from mummichog (Fundulus heteroclitus) and its application to fish virology, immunity and nanoplastics toxicology.

Application : ICC/IF

Nan H et al. J Hum Genet 2019; 64 (11) : 1055-1065 UBAP1 mutations cause juvenile-onset hereditary spastic paraplegias (SPG80) and impair UBAP1 targeting to endosomes.

Application : ICC/IF

Reactivity : Mouse

Submit a Reference

REVIEW

There are currently no reviews for MAP2 antibody (GTX133109). Be the first to share your experience with this product.

Submit a Review

Application Reference

Ruiz-Palacios M et al. Sci Total Environ 2020; 708:134821 Establishment of a brain cell line (FuB-1) from mummichog (Fundulus heteroclitus) and its application to fish virology, immunity and nanoplastics toxicology.

Application : ICC/IF

Nan H et al. J Hum Genet 2019; 64 (11):1055-1065 UBAP1 mutations cause juvenile-onset hereditary spastic paraplegias (SPG80) and impair UBAP1 targeting to endosomes.

Application : ICC/IF

Reactivity : Mouse
