APPLICATION
Application Note
*Optimal dilutions/concentrations should be determined by the researcher.
Application |
Recommended Dilution |
1:500-1:3000 |
1:100-1:1000 |
1:100-1:1000 |
1:100-1:1000 |
1:100-1:500 |
Not tested in other applications.
Calculated MW
Positive Control
HeLa , SK-N-SH , IMR32 , SK-N-AS , Neuro2A , mouse brain
Product Note
beta III Tubulin antibody [GT886] specifically recognizes endogenous levels of beta III Tubulin based on the immunogen sequence.
Predict Reactivity
Bovine, Chicken, Chimpanzee(>80% identity)
PROPERTIES
Form
Liquid
Buffer
PBS
Preservative
No preservative
Storage
Store as concentrated solution. Centrifuge briefly prior to opening vial. For short-term storage (1-2 weeks), store at 4ºC. For long-term storage, aliquot and store at -20ºC or below. Avoid multiple freeze-thaw cycles.
Concentration
1 mg/ml (Please refer to the vial label for the specific concentration.)
Antigen Species
Human
Immunogen
Carrier-protein conjugated synthetic peptide encompassing a sequence within the C-terminus region of human beta Tubulin 3/ Tuj1. The exact sequence is proprietary.
Purification
Purified by antigen-affinity chromatography.
Conjugation
Unconjugated
RRID
AB_2888258
Note
For laboratory research use only. Not for any clinical, therapeutic, or diagnostic use in humans or animals. Not for animal or human consumption.
Purchasers shall not, and agree not to enable third parties to, analyze, copy, reverse engineer or otherwise attempt to determine the structure or sequence of the product.
TARGET
Synonyms
tubulin beta 3 class III , CDCBM , CDCBM1 , CFEOM3 , CFEOM3A , FEOM3 , TUBB4 , beta-4
Background
This gene encodes a class III member of the beta tubulin protein family. Beta tubulins are one of two core protein families (alpha and beta tubulins) that heterodimerize and assemble to form microtubules. This protein is primarily expressed in neurons and may be involved in neurogenesis and axon guidance and maintenance. Mutations in this gene are the cause of congenital fibrosis of the extraocular muscles type 3. Alternate splicing results in multiple transcript variants. A pseudogene of this gene is found on chromosome 6. [provided by RefSeq]
Database
Research Area
DATA IMAGES
|
GTX631830 IHC-Fr Image
beta Tubulin 3/ TUJ1 antibody [GT886] detects beta Tubulin 3/ TUJ1 protein expression by immunohistochemical analysis. Sample: Frozen sectioned E13.5 Rat brain. Green: beta Tubulin 3/ TUJ1 protein stained by beta Tubulin 3/ TUJ1 antibody [GT886] (GTX631830) diluted at 1:250. Red: beta Tubulin 3/ TUJ1, a mature neuron marker, stained by beta Tubulin 3/ TUJ1 antibody (GTX129913) diluted at 1:250. Blue: Fluoroshield with DAPI (GTX30920).
|
|
GTX631830 ICC/IF Image
beta Tubulin 3/ Tuj1 antibody [GT886] detects beta Tubulin 3/ Tuj1 protein at cytoplasm by immunofluorescent analysis. Sample: DIV9 rat E18 primary cortical neurons were fixed in 4% paraformaldehyde at RT for 15 min. Green: beta Tubulin 3/ Tuj1 protein stained by beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830) diluted at 1:500. Red: NeuN, stained by NeuN antibody (GTX132974) diluted at 1:1000. Blue: Fluoroshield with DAPI (GTX30920).
The staining pattern is based on the publication:PMID: 30390091
|
|
GTX631830 WB Image
beta Tubulin 3/ TUJ1 antibody detects beta Tubulin 3/ TUJ1 protein by western blot analysis. Various whole cell extracts (20 μg) were separated by 10% SDS-PAGE, and the membrane was blotted with beta Tubulin 3/ TUJ1 antibody (GTX631830) diluted at a dilution of 1:1000.
|
|
GTX631830 IHC-Fr Image
beta III Tubulin antibody [GT886] detects beta III Tubulin proteins on embryonic mouse brain by immunohistochemical analysis. Sample:Frozen section of embryonic mouse brain (mE18.5). Green: beta III Tubulin antibody [GT886] (GTX631830) diluted at 1:2000. Red: Sox2 antibody (GTX101506) diluted at 1:250.
|
|
GTX631830 WB Image
Wild-type (WT) and beta Tubulin 3/ Tuj1 knockout (KO) HeLa cell extracts (30 μg) were separated by 10% SDS-PAGE, and the membrane was blotted with beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830) diluted at 1:500. The HRP-conjugated anti-mouse IgG antibody (GTX213111-01) was used to detect the primary antibody.
|
|
GTX631830 WB Image
Whole cell extract (30 μg) was separated by 10% SDS-PAGE, and the membrane was blotted with beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830) diluted at 1:1000.
|
|
GTX631830 WB Image
Mouse tissue extract (50 μg) was separated by 10% SDS-PAGE, and the membrane was blotted with beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830) diluted at 1:1000.
|
|
GTX631830 IHC-P Image
beta Tubulin 3/ Tuj1 antibody [GT886] detects beta Tubulin 3/ Tuj1 protein at cytoplasm by immunohistochemical analysis.Sample: Paraffin-embedded rat brain.beta Tubulin 3/ Tuj1 stained by beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830) diluted at 1:250.
|
|
GTX631830 IP Image
Immunoprecipitation of beta III Tubulin protein from SK-N-SH whole cell extracts using 5 μg of beta III Tubulin antibody [GT886] (GTX631830). Western blot analysis was performed using beta III Tubulin antibody [GT886] (GTX631830). EasyBlot anti-Mouse IgG (GTX221667-01) was used as a secondary reagent.
|
REFERENCE
There are currently no references for beta Tubulin 3/ Tuj1 antibody [GT886] (GTX631830). Be the first to share your publications with this product.
REVIEW
beta Tubulin 3/ Tuj1 antibody [GT886]
Cat. No. GTX631830
Rating
|
|
( Average 5 based on 1 users reviews)
|
Application
IHC (Paraffin sections)(IHC-P)
|
|
( Average 5 based on 1 users reviews)
|
Date :
Anonymous submitted on 16-Apr-2023
Application Tested :
IHC-P
Sample Species :
Rat
Sample :
Rat embryo neocortex
Blocking :
5% BSA in 0.3% Triton X-PBS, 25°C, 0.5Hr
Fixation :
4% PFA
Permeabilization /Antigen retrieval :
10 mM citrate buffer (pH6.0)
Primary Antibody :
1:1000, 4°C, 18Hr
Lane Description :
Green : GTX631830
Blue : DAPI
